Key Features
1 個 Gigabit 埠及 4 個 Gigabit PoE 埠
符合IEEE 802.3af PoE標準，安裝、配置簡單容易
9K jumbo frames提高數據傳輸速度
自動偵測和保護非標準的PoE裝置
符合IEEE 802.3x Flow Control capability標準，防止封包遺失及確保資料傳輸安全
總PoE供電預算:61.6W,每埠最高可達15.4W
先進的節能技術(IEEE 802.3az)使碳排放量降至最低
The LevelOne GEP-0520(Z) is a high-performance Gigabit PoE Switch with 4 Gigabit PoE ports and 1 Gigabit uplink port. This switch is IEEE 802.3af compliant, and provides power and data over a single Ethernet cable to any PoE device, with total PoE power budget of 61.6W, up to 15.4W per PoE port. Together with Energy Efficient Ethernet (IEEE 802.3az) standard compliant, it substantially low power consumption during periods of low-link utilization. Moreover, it supports Gigabit Ethernet connectivity with 9K jumbo frames for network performing enhancement. Ideal for small businesses that prefer an inexpensive solution for PoE deploying infrastructure.
Package Contents
GEP-0520
電源供應器
快速安裝指南
